OEM/ODM Acceptable, Manufacturer of Kiosks.
 |
| Place of Origin: | Guangdong, China |
| Brand Name: | HE |
| Certification: | CE/CCC/FCC/ROHS/ISO9001 |
| Minimum Order Quantity: | 1 unit |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard Export Packing (Foam and Wooden Crate) |
| Delivery Time: | 15-20 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 1000 pieces per month |
| Certification: | CE/CCC/FCC/ROHS/ISO9001 | Name: | Intelligent Cash Deposit Machine |
|---|---|---|---|
| Power Supply: | 110V-220V | Graphic/ Photo: | Customized |
| Warranty: | 1 Year | Application: | Bank Restaurant Coffee Shop |
| Others: | Dual 21.5 Inch CPU I5 256G | Optional Parts: | Small Bill Printer Credit Card Machine Coin Card |
| Function: | Kiosk With Card Reader | ||
| Highlight: | Biometric ATM Cash Deposit Machine |
||
Product Description
This is comprised of cutting-edge cash recyclers, which shift heavy counter transactions to self-service zone. Cash recycling technology requires less cash replenishment volume, reduce cash in transit service frequency and therefore significantly cut down the TCO of ATM operation for banks.
Features
Serial Number Tracking
Non-stop Incentive
Unrivalled Innovation
Premier Security
| Controlling Unit | Intel® Core™ i3/i5/i7 3.3Ghz CPU, 4G RAM (up to 16GB) 500G HDD (Dual HDD support), DVD-RW Windows® XP / 7 /10 |
| Banknote Processing Unit |
Deposit/dispensing speed: 8 notes per second |
Customer Interfaces
Display
-15’’ TFT color LCD with touch screen & 2*4 function keys
-Privacy filter (opt.)
-Optional brightness of screen
Keypad
-Tactile 4*4 alphanumeric keypad
-PCI compliant EPP
Card reader
-Motorized card reader, Hi-Co & Lo-Co track read
-DIP card reader (opt.)
-Contactless smart card reader/writer (opt.)
-EMV Level 1 and Level 2 compliant
-Anti-skimming design
-Card return on power failure (opt.)
-Retract card capacity: max 30 cards (opt.)
Receipt printer
-80mm 203DPI graphical thermal printer
-Capture and retract capability
Journal printer (opt.):
-High speed dot matrix journal printer
-Thermal printer
1D & 2D barcode scanner (opt.)
ADA audio
-Voice guidance support
-High quality loudspeaker and/or headset jack
Coin Dispenser (opt.)
Dispensing speed: 8 coins per second
Hopper capacity: 1.86 liters * 4 hoppers, 700-1,000 coins per hopper
Security Physical:
-Mechanical combination lock
-Electronic lock (opt.)
-Sonic alarm modules (opt.)
-UL/CEN Safe
PCI compliant EPP
EMV Level 1 and Level 2 certified
-Electro magnetic interference device
Biometric Authentication
-Palm vein reader (opt.)
-Finger vein reader (opt.)
-Finger print scanner (opt.)
-Facial recognition (opt.)
PIN Pad shield
Customer awareness mirror
DVR surveillance system (opt.)
Transaction image capture for surveillance (opt.)
SECOne for software and network security (opt.)
UPS (opt.)
Maintenance
10.4’’ LCD service panel with touch screen (available on rear access model)
Front, rear and side access
Communication
Standard TCP-IP connection
Working Environment
Temperature: Indoor: 32℉(0 ℃) to 104℉(40℃)
Outdoor: -31℉(-35℃) to 122℉(50℃)
(with optional heating unit)
Relative humidity: 20% to 95% non-condensing
* The actual capacity is subject to the thickness and fitness of local currency.
